Native Resolution WXGA 1280 x 800
Max Supported Resolution UXGA (1600 x 1200)
Brightness - BRIGHT mode1 3300 ANSI Lumens
Contrast Ratio 8000:1
Noise Level 29dB (ECO+ mode)
Lamp Life2 6000/5000/3500 (Eco+/Eco/Bright mode)
Weight / Dimensions (W x D x H) 2.2 kg / 280 x 230 x 77mm
Projection Lens F/2.57~2.84; f=21~25.6mm, 1.2x Manual Zoom
Throw Ratio 1.47 - 1.81:1 (Projection Distance:Image Width)
Projection Distance 1.2 - 10m
Image Size 0.78 – 8.02m (30.78” to 315.83”) Diagonal 16:10
Display Technology Single 0.65” WXGA DC3 DMD chip DLP® Technology by Texas Instruments
Remote Control Full function remote with laser pointer, mouse controls and direct source selecting
Inputs HDMI (HDCP) - audio supported
2 x 15 Pin D-Sub VGA Component via adaptor
S-Video 4 Pin Mini Din
Composite RCA
3.5mm Audio Mini Jack
USB (remote mouse)
Control RS232 - 9 Pin D-sub
RJ45
OUTPUT 15 Pin D-Sub VGA
3.5mm Audio Mini Jack
Audio 10W Speaker
Aspect Ratio 16:10 Native, 16:9, 4:3 Compatible
Keystone Correction ± 40° Vertical
On Screen Display 18 Languages: English, German, French, Italian, Spanish, Portuguese, Polish, Dutch, Russian, Finnish, Swedish, Greek, Norwegian/Danish, Hungarian, Czech, Turkish, Arabic & Farsi
Video Compatibility PAL SECAM 576i/p, NTSC 480i/p, HD 720p/1080i/1080p
Uniformity 85%
Displayable Colours 1.07 Billion
Horizontal Scan Rate 15.3 - 91.1kHz
Power Supply 100 - 240V, 50 - 60Hz
Power Consumption 285W BRIGHT mode < 0.5W Standby mode
230W ECO mode < 0.5W Standby mode
200W ECO+ mode < 0.5W Standby mode
Operating Conditions Operating: 5 - 40˚C, 85% Humidity (Max), 3000m Altitude (Max)
Security Security Bar, Kensington Lock Port, Password Protection
Standard Accessories Soft Carry Bag, AC Power Cord, VGA Cable, Full Function Remote, Batteries x 2, Quick Start Guide, CD User Manual, Warranty Card
RoHS Compliant
Lamp Warranty 6 months or 1000 hours - whichever comes sooner
Warranty Warranty may vary by country. Please see www.optomaeurope.com or ask your local supplier for details
Colour Guarantee3 5 Years
3D Support 120Hz frame sequential 3D for resolutions up to 720p.
60Hz field sequential 3D for resolutions up to 480i
3D Viewing Requires Optoma DLP® Link™ active shutter glasses – sold separately
3D Compatibility The 3D features of Optoma projectors can only be used with compatible 3D content. Typical applications include use with 3D educational or 3D design and modelling systems. Support for 3D TV broadcast systems, (SKY in the UK), Blu-ray 3D™ and 3D games from the Sony® PS3 or Microsoft® Xbox 360 will require the Optoma 3D-XL that is available separately.
